4-way blind actuator MIX2
Base module MIX2
Can be upgraded to maximum of 12 channels
For controlling drives for blinds, shutters, sun and vision protection devices, skylights and ventilation flaps
Up to 2 extension modules can be connected to a base module
Up to two extension modules MIX or MIX2 can be connected to one base module
Device and KNX bus module can be swapped independently of each other
Removable KNX bus module enables devices to be changed without reprogramming
Manual set-up and use of actuators is possible without KNX bus module
Free combination of switches, dimming, blinds and heating control as well as binary inputs
For controlling drives for blinds, shutters, sun and vision protection devices, skylights and ventilation flaps
Manual operation on device (even without bus connection)
LED Up and Down switching status display for each channel
Potential-free contacts for Up and Down per channel
Setting option for phase sequence and running time of device
Copy function for fast configuration
Operating voltage KNXBus voltage, <4 mAOperating voltage110 – 240 V ACStand-by consumption~0,3 WCapacity loss max.2 WFrequency50 – 60 HzNumber of channels4Width4 modulesInstallation typeDIN railType of connectionTerminal screws | Bus connection: KNX bus terminalMax. cable cross sectionSolid wire: 0.5 mm² (Ø 0.8) to 4 mm² | Stranded wire with end sleeve: 0.5 mm² to 2.5 mm²Type of contactNO contact, 6 ASwitching outputPotential-free, for SELV, if the whole device switches SELVAmbient temperature-5 °C … +45 °CType of protectionIP 20Protection classII according to EN 60 669

Havale ile Ödeme ₺11.218,92 + KDV

Kredi Kartı Tek Çekim ₺11.565,90 + KDV
